SZ 810 series Zoom-stereo Microscope
SZ 810 series zoom stereo microscope is high-end with Galilean Optical System. It has superior quality. Magnification range attains 0.65X~5.3X.
Outstanding Ergonomic Design
- SZ680/810 35°viewing angle, SZ650 40°viewing angle, suitable for long-term sitting observation.
- 330mm×300mm big stand, high stability , apply to all kinds of anatomy of specimen.
- Greenough optical system, built-in rotating shaft zoom system.
- No tilting Image in left &right light path in complete pupillary distance , No dizziness feeling after long time observing.
- (patent number: 201320807246.0)
- Stereo angle for left & right light path is 12°, stereoscopic effect, large viewing field, high zoom ration.
- High resolution, large depth of field, excellent color restoration and contrast.
- Operation comfortable(manufactured by high-precision machine, excellent assembly technology ).
- High- end material(PC resin cover, aluminium alloy ,copper alloy parts, austenite stainless steel driving parts)
| Type | SZ810 |
| Magnification Range | 0.65X~5.3X |
| Zoom Ratio | 1 : 8.1 |
| Actual Field of Image Space | Φ24 mm |
| Working Distance | 110 mm |
| Stereo Angle | 12 ° |
| Viewing Angle | 35 ° |
| Interpupillary Distance Adjustment | 50 mm~75 mm |
| Auxiliary Objective | 0.5X | 0.75X | 1X(Built-in) | 1.5X | 2X | |
| Working Distance | 189mm | 122mm | 110mm | 42mm | 36mm | |
| Eyepieces 10X /φ24mm | Magnification | 3.3 to 25.5 | 4.95 to 38.25 | 6.6 to 51 | 9.9 to 76.5 | 13.2 to 102 |
| Actual Field(mm) | 72.73 to 9.41 | 48.48 to 6.27 | 36.36 to 4.71 | 24.24 to 3.14 | 18.18 to 2.35 | |
| Eyepieces 15X/φ16mm | Magnification | 4.95 to 38.25 | 7.43 to 57.38 | 9.9 to 76.5 | 14.85 to 114.75 | 19.8 to 153 |
| Actual Field(mm) | 48.48 to 6.27 | 32.32 to 4.18 | 24.24 to 3.14 | 16.16 to 2.09 | 12.12 to 1.57 | |
| Eyepieces 20X/φ12mm | Magnification | 6.6 to 51 | 9.9 to 76.5 | 13.2 to 102 | 19.8 to 153 | 26.4 to 204 |
| Actual Field(mm) | 396.36 to 4.71 | 24.24 to 3.14 | 18.18 to 2.35 | 12.12 to 1.57 | 9.09 to 1.18 | |
SZ650/680/810 Series Zoom Stereo Microscope Outfit
| Items | SZ650BP | SZ650B2L | SZ680BP | SZ680B2L | SZ810BP | SZ810B2L | |
| Main Body | Binocular | -- | -- | -- | -- | -- | -- |
| Trinocular | ○ | ○ | ○ | ○ | |||
| 10XEyepiece/Φ22mm | -- | -- | |||||
| 10XEyepiece/Φ23mm | -- | -- | |||||
| 10XEyepiece/Φ24mm | -- | -- | |||||
| 15XEyepiece/Φ16 mm | ○○ | ○○ | ○○ | ○○ | ○○ | ○○ | |
| 20XEyepiece/Φ12mm | ○○ | ○○ | ○○ | ○○ | ○○ | ○○ | |
| 0.5X/2X Objective | ○ | ○ | ○ | ○ | ○ | ○ | |
| Focusing unit | -- | -- | -- | -- | -- | -- | |
| No light | -- | -- | -- | ||||
| Reflecting 3W LED | -- | -- | -- | ||||
| Transmitting 3W LED | -- | -- | -- | ||||
| Black & white Plate | -- | -- | -- | -- | -- | -- | |
| Glass Plate | -- | -- | -- | ||||
| Arm stand | -- | -- | -- | -- | -- | -- | |
| Pillar stand | ○ | ○ | ○ | ○ | ○ | ○ | |
| Focusing Arm stand | ○ | ○ | ○ | ○ | ○ | ○ | |
| Base (330×300mm) | -- | -- | -- | -- | -- | -- | |
| C-mount 0.5X,0.7X,1X | ○ | ○ | ○ | ○ | |||
